HANIWINNER HA238 Electric Bike Battery 36V 10Ah 360Wh Hailong 2 Rechargeable Lithium ion E-bikes Battery

Highlights

1. User-friendly Design: The light-weight design makes the battery easy to install and remove. Black hard plastic shell protects the battery effectively and LED battery level indicator can inform you of charging in time. The USB port can charge your phone and other devices outdoor. Equipped with a battery holder, just need to use the key to open the safe lock.

2. Safe to Use: Built to the highest standards that has been tested. When the motor is overloaded, the system automatically switches off to protect the technical components against damage. The battery is fully sealed and designed to be using long, even on muddy roads.

3. BMS Protection Board: The high quality battery is equipped with a 30A BMS protective plate, which prevent over charge, over discharge, over current and short circuit and ensure the long life expectancy.

4. Stable and Durable: The input and output are more stable and its large capacity makes the service life of battery longer.

5. Ergonomic Design and Widely Applicable: The electric bike battery pack has a mounting bracket that will mount to most water bottle screw holes in the frame. Compatible with 36V/48V electric bikes, bicycles, mountain bikes and more.

What’s in the box?

1 x Battery with keys
1 x Battery install plate and other parts
1 x Charger (EU plug)
1 x User Manual

Specification

Suitable Bike Brand-Including but not limited			PLENTY, SAMEBIKE, GALAXY, Giant
Model			HA238
Rated Voltage			36V
Rated Capacity			10Ah
Battery Power			360Wh
Battery capacity			2500mAh
Number of batteries			40PCS
Max Charge Voltage			42V
Discharge Cut-off Voltage			27.5V
Max. Charge Current			5A
Standard Discharge Current			5A
Max. Discharge Current(BMS)			15A
Over current protection			80A
Apply to Electric Motor Power			≤500W
Battery Charger			42V 3A
Charger specifications			42V3A
Display of power level			YES
Power level display switch			YES
Power switch			YES
USB Charging port for the phone			YES
Security lock			YES
Net weight			3.0KG
Gross weight			4.0KG
Battery size			360*100*100mm
Charger size			200x110x50mm
Operating Temperature	Charge			0~45 Celsius
	Discharge			-20~60 Celsius
	Storage	Within a month		0~45 Celsius
		Within a month to three months		5~40 Celsius
		Within three months to one year		10~35 Celsius
